The Rise of Mixture-of-Experts for Efficient Large Language Models

Updated on
Mixture of Experts Grok Mistral

In the world of natural language processing (NLP), the pursuit of building larger and more capable language models has been a driving force behind many recent advancements. However, as these models grow in size, the computational requirements for training and inference become increasingly demanding, pushing against the limits of available hardware resources.

Enter Mixture-of-Experts (MoE), a technique that promises to alleviate this computational burden while enabling the training of larger and more powerful language models. Below, we'll discuss MoE, explore its origins, inner workings, and its applications in transformer-based language models.

The Origins of Mixture-of-Experts

The concept of Mixture-of-Experts (MoE) can be traced back to the early 1990s when researchers explored the idea of conditional computation, where parts of a neural network are selectively activated based on the input data. One of the pioneering works in this field was the “Adaptive Mixture of Local Experts” paper by Jacobs et al. in 1991, which proposed a supervised learning framework for an ensemble of neural networks, each specializing in a different region of the input space.

The core idea behind MoE is to have multiple “expert” networks, each responsible for processing a subset of the input data. A gating mechanism, typically a neural network itself, determines which expert(s) should process a given input. This approach allows the model to allocate its computational resources more efficiently by activating only the relevant experts for each input, rather than employing the full model capacity for every input.

Over the years, various researchers explored and extended the idea of conditional computation, leading to developments such as hierarchical MoEs, low-rank approximations for conditional computation, and techniques for estimating gradients through stochastic neurons and hard-threshold activation functions.

Mixture-of-Experts in Transformers

Mixture of Experts

Mixture of Experts

While the idea of MoE has been around for decades, its application to transformer-based language models is relatively recent. Transformers, which have become the de facto standard for state-of-the-art language models, are composed of multiple layers, each containing a self-attention mechanism and a feed-forward neural network (FFN).

The key innovation in applying MoE to transformers is to replace the dense FFN layers with sparse MoE layers, each consisting of multiple expert FFNs and a gating mechanism. The gating mechanism determines which expert(s) should process each input token, enabling the model to selectively activate only a subset of experts for a given input sequence.

One of the early works that demonstrated the potential of MoE in transformers was the “Outrageously Large Neural Networks: The Sparsely-Gated Mixture-of-Experts Layer” paper by Shazeer et al. in 2017. This work introduced the concept of a sparsely-gated MoE layer, which employed a gating mechanism that added sparsity and noise to the expert selection process, ensuring that only a subset of experts was activated for each input.

Since then, several other works have further advanced the application of MoE to transformers, addressing challenges such as training instability, load balancing, and efficient inference. Notable examples include the Switch Transformer (Fedus et al., 2021), ST-MoE (Zoph et al., 2022), and GLaM (Du et al., 2022).

Benefits of Mixture-of-Experts for Language Models

The primary benefit of employing MoE in language models is the ability to scale up the model size while maintaining a relatively constant computational cost during inference. By selectively activating only a subset of experts for each input token, MoE models can achieve the expressive power of much larger dense models while requiring significantly less computation.

For example, consider a language model with a dense FFN layer of 7 billion parameters. If we replace this layer with an MoE layer consisting of eight experts, each with 7 billion parameters, the total number of parameters increases to 56 billion. However, during inference, if we only activate two experts per token, the computational cost is equivalent to a 14 billion parameter dense model, as it computes two 7 billion parameter matrix multiplications.

This computational efficiency during inference is particularly valuable in deployment scenarios where resources are limited, such as mobile devices or edge computing environments. Additionally, the reduced computational requirements during training can lead to substantial energy savings and a lower carbon footprint, aligning with the growing emphasis on sustainable AI practices.

Challenges and Considerations

While MoE models offer compelling benefits, their adoption and deployment also come with several challenges and considerations:

  1. Training Instability: MoE models are known to be more prone to training instabilities compared to their dense counterparts. This issue arises from the sparse and conditional nature of the expert activations, which can lead to challenges in gradient propagation and convergence. Techniques such as the router z-loss (Zoph et al., 2022) have been proposed to mitigate these instabilities, but further research is still needed.
  2. Finetuning and Overfitting: MoE models tend to overfit more easily during finetuning, especially when the downstream task has a relatively small dataset. This behavior is attributed to the increased capacity and sparsity of MoE models, which can lead to overspecialization on the training data. Careful regularization and finetuning strategies are required to mitigate this issue.
  3. Memory Requirements: While MoE models can reduce computational costs during inference, they often have higher memory requirements compared to dense models of similar size. This is because all expert weights need to be loaded into memory, even though only a subset is activated for each input. Memory constraints can limit the scalability of MoE models on resource-constrained devices.
  4. Load Balancing: To achieve optimal computational efficiency, it is crucial to balance the load across experts, ensuring that no single expert is overloaded while others remain underutilized. This load balancing is typically achieved through auxiliary losses during training and careful tuning of the capacity factor, which determines the maximum number of tokens that can be assigned to each expert.
  5. Communication Overhead: In distributed training and inference scenarios, MoE models can introduce additional communication overhead due to the need to exchange activation and gradient information across experts residing on different devices or accelerators. Efficient communication strategies and hardware-aware model design are essential to mitigate this overhead.

Despite these challenges, the potential benefits of MoE models in enabling larger and more capable language models have spurred significant research efforts to address and mitigate these issues.

Example: Mixtral 8x7B and GLaM

To illustrate the practical application of MoE in language models, let's consider two notable examples: Mixtral 8x7B and GLaM.

Mixtral 8x7B is an MoE variant of the Mistral language model, developed by Anthropic. It consists of eight experts, each with 7 billion parameters, resulting in a total of 56 billion parameters. However, during inference, only two experts are activated per token, effectively reducing the computational cost to that of a 14 billion parameter dense model.

Mixtral 8x7B has demonstrated impressive performance, outperforming the 70 billion parameter Llama model while offering much faster inference times. An instruction-tuned version of Mixtral 8x7B, called Mixtral-8x7B-Instruct-v0.1, has also been released, further enhancing its capabilities in following natural language instructions.

Another noteworthy example is GLaM (Google Language Model), a large-scale MoE model developed by Google. GLaM employs a decoder-only transformer architecture and was trained on a massive 1.6 trillion token dataset. The model achieves impressive performance on few-shot and one-shot evaluations, matching the quality of GPT-3 while using only one-third of the energy required to train GPT-3.

GLaM's success can be attributed to its efficient MoE architecture, which allowed for the training of a model with a vast number of parameters while maintaining reasonable computational requirements. The model also demonstrated the potential of MoE models to be more energy-efficient and environmentally sustainable compared to their dense counterparts.

The Grok-1 Architecture



Grok-1 is a transformer-based MoE model with a unique architecture designed to maximize efficiency and performance. Let's dive into the key specifications:

  1. Parameters: With a staggering 314 billion parameters, Grok-1 is the largest open LLM to date. However, thanks to the MoE architecture, only 25% of the weights (approximately 86 billion parameters) are active at any given time, enhancing processing capabilities.
  2. Architecture: Grok-1 employs a Mixture-of-8-Experts architecture, with each token being processed by two experts during inference.
  3. Layers: The model consists of 64 transformer layers, each incorporating multihead attention and dense blocks.
  4. Tokenization: Grok-1 utilizes a SentencePiece tokenizer with a vocabulary size of 131,072 tokens.
  5. Embeddings and Positional Encoding: The model features 6,144-dimensional embeddings and employs rotary positional embeddings, enabling a more dynamic interpretation of data compared to traditional fixed positional encodings.
  6. Attention: Grok-1 uses 48 attention heads for queries and 8 attention heads for keys and values, each with a size of 128.
  7. Context Length: The model can process sequences up to 8,192 tokens in length, utilizing bfloat16 precision for efficient computation.

Performance and Implementation Details

Grok-1 has demonstrated impressive performance, outperforming LLaMa 2 70B and Mixtral 8x7B with a MMLU score of 73%, showcasing its efficiency and accuracy across various tests.

However, it's important to note that Grok-1 requires significant GPU resources due to its sheer size. The current implementation in the open-source release focuses on validating the model's correctness and employs an inefficient MoE layer implementation to avoid the need for custom kernels.

Nonetheless, the model supports activation sharding and 8-bit quantization, which can optimize performance and reduce memory requirements.

In a remarkable move, xAI has released Grok-1 under the Apache 2.0 license, making its weights and architecture accessible to the global community for use and contributions.

The open-source release includes a JAX example code repository that demonstrates how to load and run the Grok-1 model. Users can download the checkpoint weights using a torrent client or directly through the HuggingFace Hub, facilitating easy access to this groundbreaking model.

The Future of Mixture-of-Experts in Language Models

As the demand for larger and more capable language models continues to grow, the adoption of MoE techniques is expected to gain further momentum. Ongoing research efforts are focused on addressing the remaining challenges, such as improving training stability, mitigating overfitting during finetuning, and optimizing memory and communication requirements.

One promising direction is the exploration of hierarchical MoE architectures, where each expert itself is composed of multiple sub-experts. This approach could potentially enable even greater scalability and computational efficiency while maintaining the expressive power of large models.

Additionally, the development of hardware and software systems optimized for MoE models is an active area of research. Specialized accelerators and distributed training frameworks designed to efficiently handle the sparse and conditional computation patterns of MoE models could further enhance their performance and scalability.

Furthermore, the integration of MoE techniques with other advancements in language modeling, such as sparse attention mechanisms, efficient tokenization strategies, and multi-modal representations, could lead to even more powerful and versatile language models capable of tackling a wide range of tasks.


The Mixture-of-Experts technique has emerged as a powerful tool in the quest for larger and more capable language models. By selectively activating experts based on the input data, MoE models offer a promising solution to the computational challenges associated with scaling up dense models. While there are still challenges to overcome, such as training instability, overfitting, and memory requirements, the potential benefits of MoE models in terms of computational efficiency, scalability, and environmental sustainability make them an exciting area of research and development.

As the field of natural language processing continues to push the boundaries of what is possible, the adoption of MoE techniques is likely to play a crucial role in enabling the next generation of language models. By combining MoE with other advancements in model architecture, training techniques, and hardware optimization, we can look forward to even more powerful and versatile language models that can truly understand and communicate with humans in a natural and seamless manner.
